Coal Chute

wasp-conveyors-chutes-coal

Features

  • Two Common Chute Lengths: 14′-0″ and 11’6″
  • Mechanical Catch For Extendable Insert In Retracted Position
  • Spring Assisted Crank In-Out With Plunger To Hold Chute In Intermediate Positions
  • Integrated Slip-Clutch On Crank In-Out
  • Tip Down Door Opened From Side Of Chute
  • Side Guards on Main Frame (Not Shown)

Options

  • Various Elevations
  • Rain Shield Mounting Brackets
  • Manual Extend Roller Loader To Fit Under Unit



REAR STAND FEATURES:

  • Spring Assist Pop-Up Roller To Hold Package Flow
  • Mounting Angle For Feeding Roller Section



FRONT STAND FEATURES:

  • Stabilizing Dampers Reduce Chute Rocking
  • Adjustable Discharge Elevations Via Telescoping Bottle Jack

Specifications

Dimension A
 11’6″ Version: 11′-6″
14′ Version: 14′-0″
Dimension B
 11’6″ Version: 7′-0″
14′ Version: 8’3-3/4″
Dimension C
 11’6″ Version: 75″
14′ Version: 88″
